Şekil 16.209. “Reinhard 2005” ton eşlem örneği
Özgün görüntü
Filter applied with default settings, after changing image precision in GIMP to 32-bit floating point linear light.
This filter can be used to adapt an image, which may have a high dynamic range (HDR), for presentation using a low dynamic range. This is an efficient global operator derived from simple physiological observations, producing luminance within the range 0.0-1.0.
This tonemapping approach was originally presented by Reinhard, E. and Devlin, K. (2005). “Dynamic range reduction inspired by photoreceptor physiology.” In: IEEE Transactions on Visualization and Computer Graphics, 11(1) (2005), pp. 13–24.
![]() |
Not |
---|---|
Although not as slow as the Fattal and Mantiuk filters, the Reinhard filter is not very fast on larger images. For finding the best settings for your image you could make a small relevant selection first and save that as a preset before using that for the whole image. |
“Önayarlar” birçok Renk komutu için ortak bir özelliktir. Açıklamasını için bkz: Kısım 8.1.1, “Colors Common Features”
Görüntünün genel parlaklığı.
Görüntü üzerindeki renk çeşitliliğine uyarlama.
Görüntü üzerindeki ışık çeşitliliğine uyarlama.
Bunlar Kısım 8.1.1, “Colors Common Features” adresinde açıklanan ortak özelliklerdir.
