13.6. Küçük Gezegen

13.6.1. Genel Görünüm

This filter converts a panorama into a small planet. All images don't fit this filter. The ideal image is a 360° x 180° image, also known as equirectangular image. We will see that it is possible to use normal images also.

13.6.2. Süzgeci Etkinleştirme

Bu süzgeç ana menüde SüzgeçlerEşlemKüçük Gezegen… altında bulunur.

13.6.3. Seçenekler

Şekil 17.297. Küçük Gezegen süzgeci seçenekleri

“Küçük Gezegen” süzgeci seçenekleri

Seçenekler

Önayarlar, Girdi Türü, Kırpma, Harmanlama Seçenekleri, Ön izleme, Süzgeci birleştir, Bölünmüş görünüm
[Not] Not

Bu seçenekler şurada açıklanmıştır: Kısım 2, “Ortak Özellikler”.

Kaydırma

Horizontal camera panning. If Inverse transform option is checked, the pan option moves line of sight horizontally. Else, it works as Spin option.

Eğim

Vertical camera panning. Moves line of sight upwards/downwards.

Dönüş

Spin angle around camera axis. Rotates planet around line of sight.

Yakınlaştır

Zoom level. Zooms planet in/out.

Ters dönüşüm

Do the inverse mapping; useful for touching up zenith, nadir or other parts of panorama.

Yeniden örnekleme yöntemi

Ara değerleme yöntemleri şurada açıklanmıştır: Interpolation

Kübik daha iyi sonuç verebilir.

13.6.4. Küçük Gezegen süzgecini eşdikdörtgensel görüntü ile kullanma

[İpucu] İpucu

Ücretsiz eşdiktörtgensel görüntüleri şurada bulabilirsiniz: https://commons.wikimedia.org/wiki/Category:360°_panoramas_with_equirectangular_projection.

Ettling_Isar_panorama.jpg © Simon Waldherr, CC by-sa 4.0 ile lisanslanmıştır.

GIMP opened this 16000×8000 pixels original image in a 1000×500 px frame at zoom 6.25. This is a screenshot scaled to 600×300 px. Note the empty sky, the horizon perfectly horizontal, the vanishing perspective.

Süzgeç uygulandı.

13.6.5. Using Little Planet filter with a normal image

Your panorama rarely satisfies conditions necessary for this filter, especially if you cut it off a larger image. The Little Planet filter brings left and right image sides together, and creates an unwanted sharp limit if sides are different. An uneven horizon gives an irregular circle. A blue empty sky occupying the upper half of the image and a horizontal horizon are perfect. Usually, you will have to prepare your panorama before using filter.

Şekil 17.298. Özgün görüntüler

Özgün görüntüler

Özgün panorama

Özgün görüntüler

Filter applied directly with default options


  1. Wipe sky: with Color Picker, darker blue to toolbox foreground and lighter blue to toolbox background. Rectangular selection of sky including a small part of horizon. In the selection, draw a Gradient from top to bottom.

  2. Select the left border of the image.

  3. Copy the selection and Paste it as New layer.

  4. Q shortcut to open the Align tool.

  5. Click on new layer (superimposed on selection area): new layer limits appear. Align new layer to image right side.

  6. Select>None.

  7. Yeni katmanı yatay çevir.

    New layer aligned to image right side and flipped: left and right image sides are now the same. Sky wiped out. Horizon horizontalized.

  8. Add a black Layer Mask to new layer.

  9. Apply a black-to-white gradient to layer mask.

  10. Küçük Gezegen süzgecini uygulayın.

Şekil 17.299. Sonuçlar

Sonuçlar

Hazırlanan görüntü

Sonuçlar

Süzgeç uygulandı.
